Festo MS6-LRP-1/4-D2-A8M-A5-WB Filter Regulator

- Brand: Festo
- Model: MS6-LRP-1/4-D2-A8M-A5-WB
- Type: Filter Regulator (MS series)
- Order number: 573207
  - Function: Combined filter regulator unit for compressed air preparation
  - Grid dimension: 62 mm
  - Pressure Regulation Range: 0.5 – 14 bar
  - Max Input Pressure: 20 bar
  - Nominal Flow Rate: 2300 l/min
  - Port Size: G 1/4" female
  - Bowl Capacity: 40 cm³
  - Drain Type: Manual rotary knob drain
  - Pressure Gauge: Integrated manometer
  - Lockable: Yes
  - Pressure Relief: Relieving function
  - Material: Housing aluminium, bowl polycarbonate with metal guard, filter element
  - Seal Material: NBR
  - Ambient Temperature: -10 °C to +60 °C
  - Operating Temperature : -10 °C to +60 °C
  - Protection Rating: IP65
  - Mounting: Inline or with mounting bracket
  - Features: High flow rate, compact design, integrated pressure gauge, lockable regulator knob, manual drain
- Dimensions: 280 x 200 x 150 mm
- Weight: 1.5 kg
- Country of origin: Germany
- HS code: 842139
