Festo SME-1-LED-24-B Proximity Sensor 151669

Brand: Festo
Model: SME-1-LED-24-B
Type: Proximity Sensor (Magnetic Reed)
Part Number: 151669

Technical Specs:
- Sensor Type: Magnetic reed proximity sensor
- Switching Element Function: Normally Open (N/O) contact
- Operating Voltage: 12 to 27 V AC/DC
- Output Current: Max 1000 mA
- Cable Length: 2.5 m
- Electrical Connection: 3-wire cable, open end
- Design: Block design
- Protection Rating: IP67
- Indication: Yellow LED
- Ambient Temperature: -20°C to 70°C
- Measuring Principle: Reed magnetic
- Material Information: Copper and PTFE-free
- Housing Material: high-strength plastic
- Mounting: Slot mounting, suitable for Festo cylinders with T-slot
- Additional Features:
  - Compact design for easy integration into pneumatic systems
  - LED indicator for clear status visualization
  - Robust construction for reliable operation in harsh environments
- Certifications: CE mark, RCM mark

Dimensions: 35 x 25 x 20 mm (excl. cable)

Weight: 110 g

Country of Origin: Germany

HS Code: 8536.50
