Jumo Compact Feedback Controller dTRON 703044-181-000-23/000

Jumo Compact Feedback Controller dTRON 703044-181-000-23/000

Jumo Compact Feedback Controller dTRON 304
  • Potentiometer Input Type Min. 100 Ohm
  • Potentiometer Input Type Max. 4 kOhm
  • Heating Current Input Type 0 ... 50 mA
  • Logic Unit Input Type Floating Contact
  • Measurement Input Universal
  • Output Type Analogue
  • Logic
  • Relay
  • Analogue Output Type 0/2 ... 10 V
  • 0/4 ... 20 mA
  • Logic Unit Output Type 0 ... 12 V @ 30 mA
  • 0 ... 18 V @ 25 mA
  • Transmitter Feed Output Type 20 mA @ 17 V
  • Relay Output Type 3 A @ 230 VAC
  • Display Type LCD
  • Functions Controller
  • Control Function PD
  • Operating Voltage Min. 110 VAC
  • Operating Voltage Max. 240 VAC
  • Protection Rating IP20
  • IP65
  • Mounting Type Panel Mount
  • Set Value Min. 0
  • Set Value Max. 9999
  • Cycle Time 250 ms
  • Cut-Out Width 92 mm
  • Cut-Out Height 92 mm
  • Panel Depth 90 mm
  • Be aware No mounting brackets !!
$72.67

Original: $242.22

-70%
Jumo Compact Feedback Controller dTRON 703044-181-000-23/000—

$242.22

$72.67
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6

Description

Jumo Compact Feedback Controller dTRON 304
  • Potentiometer Input Type Min. 100 Ohm
  • Potentiometer Input Type Max. 4 kOhm
  • Heating Current Input Type 0 ... 50 mA
  • Logic Unit Input Type Floating Contact
  • Measurement Input Universal
  • Output Type Analogue
  • Logic
  • Relay
  • Analogue Output Type 0/2 ... 10 V
  • 0/4 ... 20 mA
  • Logic Unit Output Type 0 ... 12 V @ 30 mA
  • 0 ... 18 V @ 25 mA
  • Transmitter Feed Output Type 20 mA @ 17 V
  • Relay Output Type 3 A @ 230 VAC
  • Display Type LCD
  • Functions Controller
  • Control Function PD
  • Operating Voltage Min. 110 VAC
  • Operating Voltage Max. 240 VAC
  • Protection Rating IP20
  • IP65
  • Mounting Type Panel Mount
  • Set Value Min. 0
  • Set Value Max. 9999
  • Cycle Time 250 ms
  • Cut-Out Width 92 mm
  • Cut-Out Height 92 mm
  • Panel Depth 90 mm
  • Be aware No mounting brackets !!
