Parker Lucifer 341N01 NAMUR Solenoid Valve

Brand: Parker Lucifer (Parker Hannifin)
Model: 341N01
Type: NAMUR Solenoid Valve
Part Number: 2341NAKBJNM1

Technical Specs:
- Valve Type: NAMUR spool valve, heavy-duty & pilot operated
- Orifice Size: DN4
- Flow Coefficient: 600 L/min
- Operating Pressure Range: 1 to 10 bar
- Media: Compressed air, neutral gases
- Seal Material: NBR
- Voltage: Configurable
- Electrical Connection: DIN 43650 Form A
- Enclosure Rating: IP65
- Ambient Temperature Range: -25°C to +80°C
- Housing Material: Anodised aluminium
- Atex: II 1/2/3 GDcTX
- Additional Features:
  - Full range of functions including 3/2, 5/2, 5/3
  - Solenoid or air operated
  - Robust design for heavy-duty applications

Dimensions: 145 x 75 x 35 mm

Weight: 320 g

Country of Origin: Switzerland

HS Code: 8481.80
