Pepperl + Fuchs Z728 Zener Barrier

Pepperl + Fuchs Z728 Zener Barrier

  • Pepperl + Fuchs
  • Z728
  • Zener Barrier
  • P/N: 71788
  • 1-Channel
  • Working Voltage 26.5V at 10 µA
  • Series Resistance max. 327 Ω
  • Fuse Rating 50 mA
  • DIN rail mountable
  • The Zener Barrier prevents the transfer of unacceptably high energy from the safe area into the hazardous area.
  • The Zener diodes in the Zener Barrier are connected in the reverse direction. The breakdown voltage of the diodes is not exceeded in normal operation. If this voltage is exceeded, due to a fault in the safe area, the diodes start to conduct, causing the fuse to blow. The Zener Barrier has a positive polarity, i. e. the anodes of the zener diodes are grounded.
$6,429.52

Original: $21,431.73

-70%
Pepperl + Fuchs Z728 Zener Barrier—

$21,431.73

$6,429.52
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6
Product image 7

Description

  • Pepperl + Fuchs
  • Z728
  • Zener Barrier
  • P/N: 71788
  • 1-Channel
  • Working Voltage 26.5V at 10 µA
  • Series Resistance max. 327 Ω
  • Fuse Rating 50 mA
  • DIN rail mountable
  • The Zener Barrier prevents the transfer of unacceptably high energy from the safe area into the hazardous area.
  • The Zener diodes in the Zener Barrier are connected in the reverse direction. The breakdown voltage of the diodes is not exceeded in normal operation. If this voltage is exceeded, due to a fault in the safe area, the diodes start to conduct, causing the fuse to blow. The Zener Barrier has a positive polarity, i. e. the anodes of the zener diodes are grounded.
