Pilz PNOZ 6 Safety Relay

Pilz PNOZ 6 Safety Relay

  • Brand: Pilz
  • Range: PNOZ
  • Model: 6
  • Type: Safety Relay
  • Part Number: 474899
  • Supply Voltage: 24 V DC
  • Safety Contacts: 3 safety contacts (NO), instantaneous
  • Auxiliary Contacts: 1 auxiliary contact (NO)
  • Rated Operational Current:
  • Safety Contacts: Up to 8 A at 24 V DC
  • Auxiliary Contact: Up to 8 A at 24 V DC
  • Response Time: Typically 15 ms
  • Mounting: DIN rail
  • Dimensions: 87 × 45 × 121 mm
  • Applications:
  • The PNOZ 6 is suitable for applications requiring the monitoring of emergency stop circuits, safety gates, light curtains, and other safety-related functions. It is commonly used in machinery, conveyor systems, and automated production lines to ensure compliance with safety standards and protect personnel.
$62.20

Original: $207.34

-70%
Pilz PNOZ 6 Safety Relay—

$207.34

$62.20
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6
Product image 7

Description

  • Brand: Pilz
  • Range: PNOZ
  • Model: 6
  • Type: Safety Relay
  • Part Number: 474899
  • Supply Voltage: 24 V DC
  • Safety Contacts: 3 safety contacts (NO), instantaneous
  • Auxiliary Contacts: 1 auxiliary contact (NO)
  • Rated Operational Current:
  • Safety Contacts: Up to 8 A at 24 V DC
  • Auxiliary Contact: Up to 8 A at 24 V DC
  • Response Time: Typically 15 ms
  • Mounting: DIN rail
  • Dimensions: 87 × 45 × 121 mm
  • Applications:
  • The PNOZ 6 is suitable for applications requiring the monitoring of emergency stop circuits, safety gates, light curtains, and other safety-related functions. It is commonly used in machinery, conveyor systems, and automated production lines to ensure compliance with safety standards and protect personnel.
