Power Electronics SD300242 Variable Speed Drive
- Brand: Power Electronics
- Model: SD300242
- Type: Variable Speed Drive
- Technical Specifications:
- Function: High-performance general purpose AC drive for demanding heavy-duty applications requiring high starting torque and precise control
- Power Rating: 0.75 - 0.4 kW (ND/HD dual duty rating)
- Input Voltage: 380/480V x 3
- Output Voltage: 0 - input voltage
- Output Current: 1.3 A
- Output Frequency: 0-400 Hz
- Enclosure Rating: IP20
- Control Modes: Sensorless vector control, V/f control, PI controller
- Safety Features: Safe Torque Off (STO) built-in
- Communication: Modbus RTU standard
- EMC Filter: Built-in Class A1 (EN 55011)
- Operating Temperature: -10°C to +50°C (IP20)
- Protection: Overload, short-circuit, overvoltage, earth fault protection
- Dimensions: 128 x 123 x 68 mm - Frame 1N
- Weight: 900 g
- Country of Origin: Spain
- HS Code: 85044082
Original: $338.21
-70%$338.21
$101.46
Description
- Brand: Power Electronics
- Model: SD300242
- Type: Variable Speed Drive
- Technical Specifications:
- Function: High-performance general purpose AC drive for demanding heavy-duty applications requiring high starting torque and precise control
- Power Rating: 0.75 - 0.4 kW (ND/HD dual duty rating)
- Input Voltage: 380/480V x 3
- Output Voltage: 0 - input voltage
- Output Current: 1.3 A
- Output Frequency: 0-400 Hz
- Enclosure Rating: IP20
- Control Modes: Sensorless vector control, V/f control, PI controller
- Safety Features: Safe Torque Off (STO) built-in
- Communication: Modbus RTU standard
- EMC Filter: Built-in Class A1 (EN 55011)
- Operating Temperature: -10°C to +50°C (IP20)
- Protection: Overload, short-circuit, overvoltage, earth fault protection
- Dimensions: 128 x 123 x 68 mm - Frame 1N
- Weight: 900 g
- Country of Origin: Spain
- HS Code: 85044082
