Siemens 3RT1016-1BB42 Contactor
- Brand: Siemens
- Model: 3RT1016-1BB42
- Type: Contactor
- Technical Specifications:
- Series: SIRIUS 3RT1
- Function: 3-pole contactor for switching motors
- Rated Operational Voltage: 400 V AC (AC-3)
- Rated Operational Current:
- AC-3: 9 A
- AC-1: 22 A
- Power Rating:
- 3-phase: 4 kW at 400 V (AC-3)
- 2 HP at 230 V, 3 HP at 460 V
- Control Voltage: 24 V DC
- Number of Poles: 3
- Auxiliary Contacts: 1 NC
- Connection Type: Screw terminals
- Frame Size: S00
- Operating Temperature: -25°C to +60°C
- Protection Rating: IP20
- Standards: IEC 60947, UL, CSA compliant
- Features: High contact reliability, climate-resistant, IE3/IE4-ready, combinable with SIRIUS modular system accessories (e.g., auxiliary contact blocks, surge suppressors)
- Dimensions: 80 mm x 62 mm x 50 mm
- Weight: 300 g
- Country of Origin: Germany
- HS Code: 85364900
Original: $60.70
-70%$60.70
$18.21
Description
- Brand: Siemens
- Model: 3RT1016-1BB42
- Type: Contactor
- Technical Specifications:
- Series: SIRIUS 3RT1
- Function: 3-pole contactor for switching motors
- Rated Operational Voltage: 400 V AC (AC-3)
- Rated Operational Current:
- AC-3: 9 A
- AC-1: 22 A
- Power Rating:
- 3-phase: 4 kW at 400 V (AC-3)
- 2 HP at 230 V, 3 HP at 460 V
- Control Voltage: 24 V DC
- Number of Poles: 3
- Auxiliary Contacts: 1 NC
- Connection Type: Screw terminals
- Frame Size: S00
- Operating Temperature: -25°C to +60°C
- Protection Rating: IP20
- Standards: IEC 60947, UL, CSA compliant
- Features: High contact reliability, climate-resistant, IE3/IE4-ready, combinable with SIRIUS modular system accessories (e.g., auxiliary contact blocks, surge suppressors)
- Dimensions: 80 mm x 62 mm x 50 mm
- Weight: 300 g
- Country of Origin: Germany
- HS Code: 85364900
