Siemens Siparts DR24 6DR2410-5

Brand: Siemens

Model: SIPART DR24 (Part Number: 6DR2410-5)

Type: Multifunction Process Controller

All tech specs
- Power supply: AC 230/115 V (switchable)
- Analog inputs: 3 x 0/4-20 mA or 0/2-10 V
- Analog outputs: 3 x 0/4-20 mA
- Digital inputs: 4 x DC 24 V
- Digital outputs: 8 x DC 24 V
- Capable of up to 4 independent control loops
- Freely configurable for various control tasks (e.g., single-channel, dual-channel, or complex with additional computing functions)
- CMOS technology CPU
- Protection class: IP20 (front IP64 with optional cover)
- Display and operation via front panel
- Serial interface option available
- Supports various control algorithms and functions (PID, ratio, cascade, etc.)

Dimension
- Width: 72 mm
- Height: 144 mm
- Depth: Approximately 200-250 mm (standard panel-mount depth for SIPART DR series)

Weight
1.1 kg

Country of origin
Germany

HS code
90328900
