Insert Deal R4160 Pressure Regulator
- Brand: Insert Deal
- Series: R4
- Type: Low Pressure Gas Regulator
- Model: R4160
- Part Number: R4160
- Pressure: Maximum inlet pressure: 6 bar
- Material: Aluminium body with 316L stainless steel internal components
- Weight: 1.3 kg
-
Dimensions: 160 x 160 x 180mm
- Inlet Connection: 1/2" BSP
- Outlet Connection: 3/4" BSP
- Gauge Ports: 1/4" BSP
- Outlet Pressure Range: 20–200 mbar, or 150–700 mbar
- Design Type: Non-relieving, balanced main valve with diaphragm
- Fluid Compatibility: Suitable for compressed air and gases such as N₂, He, Ar, H₂, C₃H₈, CH₄, CO₂, N₂O, and NH₃
Select Condition
From $101.94
Original: $339.81
-70%Insert Deal R4160 Pressure Regulator—
$339.81
$101.94
Description
- Brand: Insert Deal
- Series: R4
- Type: Low Pressure Gas Regulator
- Model: R4160
- Part Number: R4160
- Pressure: Maximum inlet pressure: 6 bar
- Material: Aluminium body with 316L stainless steel internal components
- Weight: 1.3 kg
-
Dimensions: 160 x 160 x 180mm
- Inlet Connection: 1/2" BSP
- Outlet Connection: 3/4" BSP
- Gauge Ports: 1/4" BSP
- Outlet Pressure Range: 20–200 mbar, or 150–700 mbar
- Design Type: Non-relieving, balanced main valve with diaphragm
- Fluid Compatibility: Suitable for compressed air and gases such as N₂, He, Ar, H₂, C₃H₈, CH₄, CO₂, N₂O, and NH₃
