DAB Nova 200 MNA 40th Submersible Drainage Pump
- Brand: DAB
- Model: Nova 200 MNA 40th
- Type: Submersible Drainage Pump
- Part Number: 60194402H
- Technical Specs:
- Pump Type: Submersible centrifugal pump for clean and slightly dirty water
- Motor Power: 350 W (0.3 HP)
- Voltage: 1 × 230 V AC, 50 Hz
- Rated Current: 1.5 A
- Maximum Head: 6.1 m
- Maximum Flow Rate: 12 m³/h
- Maximum Immersion Depth: 7 m
- Discharge Connection: Hose connection
- Cable Length: 10 m
- Operating Temperature: 0 °C to +35 °C (liquid)
- Motor Protection: Thermal overload protection
- Insulation Class: F
- Protection Class: IP68
- Materials:
- Pump Body: Technopolymer (composite)
- Impeller: Noryl (technopolymer)
- Shaft: Stainless steel AISI 431
- Additional Features:
- 40th Anniversary Edition
- Vortex impeller for better solids handling
- Low suction level
- Silent operation and high reliability
- Built-in thermal protection
- Easy to install and maintain
Dimensions: 170 x 130 x 280 mm
Weight: 4.8 kg
Country of Origin: Hungary
HS Code: 8413.70
Description
- Brand: DAB
- Model: Nova 200 MNA 40th
- Type: Submersible Drainage Pump
- Part Number: 60194402H
- Technical Specs:
- Pump Type: Submersible centrifugal pump for clean and slightly dirty water
- Motor Power: 350 W (0.3 HP)
- Voltage: 1 × 230 V AC, 50 Hz
- Rated Current: 1.5 A
- Maximum Head: 6.1 m
- Maximum Flow Rate: 12 m³/h
- Maximum Immersion Depth: 7 m
- Discharge Connection: Hose connection
- Cable Length: 10 m
- Operating Temperature: 0 °C to +35 °C (liquid)
- Motor Protection: Thermal overload protection
- Insulation Class: F
- Protection Class: IP68
- Materials:
- Pump Body: Technopolymer (composite)
- Impeller: Noryl (technopolymer)
- Shaft: Stainless steel AISI 431
- Additional Features:
- 40th Anniversary Edition
- Vortex impeller for better solids handling
- Low suction level
- Silent operation and high reliability
- Built-in thermal protection
- Easy to install and maintain
Dimensions: 170 x 130 x 280 mm
Weight: 4.8 kg
Country of Origin: Hungary
HS Code: 8413.70
