EGE-Elektronik Spezial-Sensoren IGMP 010 GSP Inductive Polar Switch

- Brand: EGE-Elektronik Spezial-Sensoren GmbH

- Model: IGMP 010 GSP

- Type: Inductive Polar Switch

- Part number: P31219

Technical specifications:
- Sensing range: 10 mm
- Housing: M30 x 1 threaded cylindrical
- Output: PNP-NO
- Supply voltage: 10–30 V DC
- Switching current: Max. 200 mA
- Short-circuit proof: Yes
- Reverse polarity protection: Yes
- Voltage drop: Max. 2 V
- Current consumption: 4 mA
- Switching frequency: 1000 Hz
- Ambient temperature: -55°C to +60°C (operating); limit temperature -60°C
- Temperature gradient: Max. 5 K/min
- Degree of protection: IP68 + IP69K
- Housing material: Stainless steel AISI 316 Ti (A4) + PTFE
- Connection: 2 m FEP cable (3 x 0.34 mm²; halogen-free, low-temperature resistant)
- Additional features: Specially sealed for extreme low temperatures down to -60°C; resistant to high-pressure cleaning; insensitive to ice buildup or condensation in cold environments; suitable for detection of baskets, trolleys, valve settings, flaps, or metal objects in refrigeration areas
- Standards: Compliant with IEC/EN 60947-5-2; CE marked

Weight: 400 g

Dimensions: 235 x 100 x 50 mm

Country of origin: Germany

HS code: 8536.50
