Endress+Hauser Cerabar PMC731 Digital Pressure Transmitter

- Brand: Endress+Hauser

- Model: Cerabar PMC731

- Order Code: PMC731-G31K1M1AG1

- Type: Digital Pressure Transmitter

- All tech specs:
- Measuring principle: Capacitive
- Measuring range: -1....2 bar
- Overload resistance: Very high
- Minimum pressure: 0.1 bar
- Maximum pressure: 20 bar
- Turndown ratio: Up to 100:1
- Process temperature: -20 °C to +100 °C
- Ambient temperature: -20 °C to +80 °C
- Output signal: 4...20 mA (analog, 2-wire) with HART communication
- Power supply: 11.5...30 V DC
- Process connection: Threaded G2"
- Wetted parts: Ceramic diaphragm
- Housing: Aluminium
- Protection class: IP65
- Display / Operation: LCD Display
- Features: High overload and vacuum resistance, wear-free ceramic cell, self-diagnostics, suitable for hygienic/clean processes, modular design
- Approvals: ATEX 4500 II 1/2 G, EExia IIc T6, FM, CSA, SIL capable
- Part of legacy Cerabar S series: Obsolete product

Dimensions: 200 x 160 x 120 mm

Weight: 2.1 kg

Country of origin: Germany

HS code: 902620
