Fanal Elektrik TW113-B Thermostat

- Brand: Fanal Elektrik (Westinghouse)
- Model: TW113-B
- Type: Thermostat (Frost monitor)
- Tech specs:
  - Function: Temperature control for air-con, refrigeration & heating systems
  - Control Principle: Bimetal strip
  - Temperature Range: 2 – 20 °C
  - Switching Differential: ≈ 3.5 K
  - Switching Capacity: 10 (4) A at 380 V AC
  - Contact Type: Changeover (SPDT) – heating / off / cooling
  - Connection: 3-wire (L, N, switching contact)
  - Mounting: Surface mount on wall
  - Sensor Location: Internal bimetal sensor
  - Protection Rating: IP20
  - Operating Temperature: 0 – 40 °C (ambient)
  - Features: Frost protection function (activates at ≈ 5 °C) no battery or power required, classic mechanical design, discontinued
- Dimensions: 190 x 110 x 70 mm
- Weight: 950 g
- Country of origin: Germany
- HS code: 903210
