Jola SMG/E -D- Side-Mount Float Switch

- Brand: Jola (Jola Spezialschalter GmbH & Co. KG)

- Model: SMG/E -D-

- Type: Side-Mount Float Switch

- Part number: SMG/E -D-

- Technical specifications:
- Mounting: Side-mount
- Switch function: Microswitch
- Switching capacity: 24 - 250 V AC / 0.02 - 0.5 A
- Switching points: 1 switching point
- Float material: Stainless steel 1.4571 (316Ti)
- Process connection: G1" thread
- Pressure range: Up to 10 bar
- Temperature range: 0°C to +80°C
- Protection class: IP54
- Cable entry: M20
- Additional features: High reliability and long life (>10^6 switches); suitable for aggressive media: low maintenance;  compact design for side installation
- Standards: Compliant with DIN/EN for level switches; CE marked

Weight: 800 g

Dimensions: 400 x 140 x 100 mm

Country of origin: Germany

HS code: 8536.50
