Martens Elektronik DMS9648-1-2R-AO-0-00-N/cm2 Signal Panel Meter

- Brand: Martens Elektronik (GHM Group / Senseca)

- Model: DMS9648

- Type: Signal Panel Meter

- Part number: DMS9648-1-2R-AO-0-00-N/cm²

- Technical specifications:
- Display: LED red, 14.2 mm high digits; range ±9999(0) digits
- Input: DMS bridge / strain gauge
- Measuring input: For mV/V signals from DMS bridges; high resolution, teach-in function for easy calibration, tare function
- Scaling / units: Freely programmable indicating range, decimal point, and engineering units (e.g., N/cm² as specified for direct pressure/force readout)
- Analog output: AO 0/4–20 mA
- Relays / outputs: 2R
- Power supply: Typically 230 V AC
- Additional features: Teach-in / auto-calibration, tare, min/max value storage, programmable parameter set; error indication; suitable for force/pressure/torque measurement in industrial applications
- Protection: Front IP65
- Standards: Compliant with relevant IEC/EN for panel meters

Weight: 450 g

Dimensions: 110 x 100 x 50 mm

Country of origin: Germany

HS code: 9030.33
