Mennekes Powertop Xtra Industrial CEE Connector/Coupler

- Brand: Mennekes

- Model: PowerTOP Xtra

- Part number: 14212

- Type: Industrial CEE Connector / Coupler (Female)

- All tech specs
- Rated current: 63 A
- Number of poles: 5-pole (3P + N + PE / 3 phases + neutral + earth)
- Rated voltage: 380-415 V (nominal 400 V)
- Clock position (earth/keying): 6 h
- Color code: Red
- Protection class: IP67
- Connection type: Screw terminals
- Cable entry: Screwed cable gland with integrated sealing
- Cable cross-section: Typically 6-16 mm²
- Contact material: Nickel-plated contacts (highly heat-resistant contact carrier)
- Housing material: Plastic (highly heat-resistant)
- Features: Rubberised grip surfaces for secure handling, integrated strain relief and kink protection, enclosure with threaded lock
- Standards compliance: IEC 60309-2 / EN 60309-2
- Suitable for: Heavy-duty industrial applications, construction sites, temporary power, generators, marine, events, high IP protection needs

Dimensions: 270 x 130 x 110 mm

Weight: 1.1 kg

Country of origin: Germany

HS code: 853669
