Schneider Electric GV4P80B Motor Circuit Breaker
- Brand: Schneider Electric
- Model: GV4P80B (part of TeSys GV4 / TeSys Deca series)
- Type: Motor Circuit Breaker (MPCB) / Motor Protection Circuit Breaker, Thermal-Magnetic
- Part number: GV4P80B
- Technical specifications:
- Poles: 3P
- Rated current: 40 - 80 A
- Rated operational voltage: Up to 690 V AC
- Frequency: 50/60 Hz
- Breaking capacity (Icu): 25 kA at 380–415 V AC / 400 V (IEC 60947-2); 50 kA at 220–240 V AC
- Protection type: Thermal-magnetic
- Motor power protected: 37–55 kW at 500/690 V
- Terminals: Everlink terminals
- Impulse withstand voltage: 8 kV (IEC 60947-2)
- Power dissipation: Approx. 4.6 W
- Mechanical durability: Up to 40,000 cycles
- Electrical durability: Varies by load
- Operating rate: 25 cycles/hour
Weight: 1.9 kg
Dimensions: 220 x 100 x 210 mm
Country of origin: Poland
HS code: 8536.20
Original: $60,212.96
-70%$60,212.96
$18,063.89
Description
- Brand: Schneider Electric
- Model: GV4P80B (part of TeSys GV4 / TeSys Deca series)
- Type: Motor Circuit Breaker (MPCB) / Motor Protection Circuit Breaker, Thermal-Magnetic
- Part number: GV4P80B
- Technical specifications:
- Poles: 3P
- Rated current: 40 - 80 A
- Rated operational voltage: Up to 690 V AC
- Frequency: 50/60 Hz
- Breaking capacity (Icu): 25 kA at 380–415 V AC / 400 V (IEC 60947-2); 50 kA at 220–240 V AC
- Protection type: Thermal-magnetic
- Motor power protected: 37–55 kW at 500/690 V
- Terminals: Everlink terminals
- Impulse withstand voltage: 8 kV (IEC 60947-2)
- Power dissipation: Approx. 4.6 W
- Mechanical durability: Up to 40,000 cycles
- Electrical durability: Varies by load
- Operating rate: 25 cycles/hour
Weight: 1.9 kg
Dimensions: 220 x 100 x 210 mm
Country of origin: Poland
HS code: 8536.20
