Schneider Electric Pro-face GP-4501TW Touch Screen Panel
- Brand: Schneider Electric
- Model: Pro-face GP-4501TW
- Type: Touch Screen Panel
- Part number: PFXGP4501TADW
Technical specifications:
- Display: 10.4" TFT Colour LCD
- Touch screen: Analog resistive touch
- Processor: RISC CPU (32-bit)
- Memory: 16 MB Application, Data backup 128 KB
- Configuration software: Vijeo Designer
- Interfaces:
- 1 x Ethernet (RJ45; 10/100 Mbps; Modbus TCP, Ethernet/IP, PROFINET)
- 2 x RS232/RS422/RS485 (COM1 and COM2; serial communication)
- 1 x USB Host (for USB flash drive, barcode reader, printer)
- 1 x USB Device (for programming/transfer)
- SD card slot (for project backup, data logging, recipe storage)
- Power supply: 24 V DC (permissible range 19.2–28.8 V DC; consumption approx. 20–25 W)
- Operating temperature: 0°C to +55°C (vertical installation)
- Protection: IP65 front (with gasket); IP20 rear
- Mounting: Panel mount
- Additional features: No integrated keys/buttons (pure touch); alarm management; recipe handling; trend curves; multilingual support; password protection; high-brightness display; legacy model
- Standards: IEC/EN compliant for HMI panels; CE, UL, cULus approvals
Status: Discontinued
Weight: 3.1 kg
Dimensions: 390 x 320 x 200 mm
Country of origin: Indonesia
HS code: 8537.10
Original: $685.37
-70%$685.37
$205.61
Description
- Brand: Schneider Electric
- Model: Pro-face GP-4501TW
- Type: Touch Screen Panel
- Part number: PFXGP4501TADW
Technical specifications:
- Display: 10.4" TFT Colour LCD
- Touch screen: Analog resistive touch
- Processor: RISC CPU (32-bit)
- Memory: 16 MB Application, Data backup 128 KB
- Configuration software: Vijeo Designer
- Interfaces:
- 1 x Ethernet (RJ45; 10/100 Mbps; Modbus TCP, Ethernet/IP, PROFINET)
- 2 x RS232/RS422/RS485 (COM1 and COM2; serial communication)
- 1 x USB Host (for USB flash drive, barcode reader, printer)
- 1 x USB Device (for programming/transfer)
- SD card slot (for project backup, data logging, recipe storage)
- Power supply: 24 V DC (permissible range 19.2–28.8 V DC; consumption approx. 20–25 W)
- Operating temperature: 0°C to +55°C (vertical installation)
- Protection: IP65 front (with gasket); IP20 rear
- Mounting: Panel mount
- Additional features: No integrated keys/buttons (pure touch); alarm management; recipe handling; trend curves; multilingual support; password protection; high-brightness display; legacy model
- Standards: IEC/EN compliant for HMI panels; CE, UL, cULus approvals
Status: Discontinued
Weight: 3.1 kg
Dimensions: 390 x 320 x 200 mm
Country of origin: Indonesia
HS code: 8537.10
