Siemens 3RK2400-1FQ03-0AA3 Digital I/O Compact Module
- Brand: Siemens
- Model: 3RK2400-1FQ03-0AA3
- Type: Digital I/O Compact Module K60
- All tech specs
- Function: Compact AS-i I/O module for connecting binary sensors/actuators to the AS-Interface bus
- AS-Interface Version: AS-i 3.0
- Inputs: 4 digital inputs
- Input Current: ≈ 6 mA per input
- Input Delay: 1.5 ms
- Outputs: 3 digital outputs
- Total Output Current: Max. 2 A
- Short-circuit Protection: Yes
- Supply Voltage: via AS-i bus
- Power Consumption: Max. 200 mA from AS-i bus
- Connection: Screw terminals
- Mounting: DIN rail or direct mounting
- Protection Rating: IP67
- Operating Temperature: -25 °C to +85 °C
- Storage Temperature: -40 °C to +85 °C
- LED Indicators: Power, I/O status, AS-i communication
- Diagnostics: Short-circuit, overload, peripheral fault
- Features: High channel density, supports safety-related signals, easy parameterisation
Dimensions: 150 x 60 x 30 mm
Weight: 250 g
Country of origin: Germany
HS code: 853710
