Siemens 7KM2111-1BA00-3AA0 Monitoring Device

- Brand: Siemens

- Model: SENTRON PAC3200

- Type: Monitoring Device / Measuring Device

- Part number: 7KM2111-1BA00-3AA0

Technical specifications:
- Display: LCD graphical display
- Measured voltage range: L-L up to 500 V AC, L-N up to 289 V AC
- Measured current: 5 A
- System: 3-phase
- Measured values: Over 50 parameters including voltage, current, active/reactive/apparent power, power factor, frequency, energy , harmonics, min/max values, mean values, demand, universal counter, working hours counter
- Accuracy: Class 0.5 for energy; high measuring accuracy for industrial use
- Interfaces: Modbus TCP integrated (Ethernet)
- Power supply: 22–65 V DC
- Additional features: Min/max/slave pointer function; configurable limits/alarms; digital input/output; password protection; intuitive menu via 4 keys or communication; backlighting adjustable; suitable for energy management, load monitoring, LEED credits, critical equipment oversight
- Mounting: Panel mount
- Standards: IEC/EN compliant; UL61010-1, CE

Status: Discontinued

Weight: 500 g

Dimensions: 130 x 110 x 80 mm

Country of origin: Hungary

HS code: 9030.31
