TP-Link TL-SG1005 Industrial Ethernet Switch

Brand: TP-Link
Model: TL-SG1005
Type: Industrial Ethernet Switch
Part Number: TL-SG1005

Technical Specs:
- Ports: 5 x 10/100/1000 Mbps RJ45 auto-negotiation ports (Gigabit Ethernet)
- Switching Capacity: 10 Gbps
- Forwarding Rate: 7.4 Mpps
- MAC Address Table: 2 K
- Jumbo Frame: 10 KB
- Transmission Method: Store-and-forward
- Switching Mode: Auto MDI/MDIX
- Flow Control: IEEE 802.3x flow control for full duplex
- Power: 12V/24V/48V DC - Screw terminal
- Energy Efficient: IEEE 802.3az Energy Efficient Ethernet (EEE)
- LED Indicators: Power, link/activity per port
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -40°C to 70°C
- Operating Humidity: 10% to 90% RH non-condensing
- Port Alarm: Dip switch toggle
- Housing Material: Metal
- Mounting: Frame-mountable

Dimensions: 138 x 100 x 38 mm

Weight: 200 g

Country of Origin: China

HS Code: 8517.62
