Vega Vegabar 82 Pressure Transmitter - B82.AXDUSHGGSHX8SMXX

- Brand: VEGA

- Model: VEGABAR 82

- Code: B82.AXDUSHGGSHX8SMXX

- Type: Pressure Transmitter

- All tech specs:
- Measuring principle: Ceramic capacitive dry measuring cell (CERTEC®)
- Range: 0 ... +10 bar
- Process pressure (max) : -1 ... +900 bar (90,000 kpa)
- Process fitting: G 1/2" EN837
- Output signal: 4 ... 20 mA/Two wire/HART
- Approvals: Explosion proof areas, FM, ship approvals, hygienic approvals
- Temperature range: -15....130 C
- Housing: Stainless steel single chamber
- Protection rating: IP66/IP67/IP68 NEMA 6P
- Wetted parts: FFKM.316L

- Cable length: 10 m PUR

Dimensions: 160 x 120 x 40 mm

Weight: 2.3 kg

Country of origin: Germany

HS code: 902620
